1.Material: 100% new PE, PP, PA for chosen.
2.Features: smooth body without burr, good flexibility, anti-corrosion, waterproof and oilproof, high and low temperature resistant, insulation flame retardant.
3.Color: Grey, Black, other colors are available as requested.
4.Usage: specially used for automobile wiring, and also used in machine tool, automatic instrumentation motors, to protect cables and wires from external force, and to resist abrasion and insulation.
5.Certificates: CE, RoHS, REACH, SGS
Item No. | Outer Diameter | Inner Diameter | Bending radius | Package | |||
mm | inch | mm | inch | mm | inch | meters/roll | |
NLCT-AD7.5 | 7.5 | 0.30 | 5.5 | 0.22 | 16 | 0.63 | 100 |
NLCT-AD10 | 10 | 0.39 | 6.5 | 0.26 | 16 | 0.63 | 100 |
NLCT-AD11.6 | 11.6 | 0.46 | 8 | 0.31 | 20 | 0.79 | 100 |
NLCT-AD13 | 13 | 0.51 | 10 | 0.39 | 20 | 0.79 | 100 |
NLCT-AD15.8 | 15.8 | 0.62 | 12 | 0.47 | 30 | 1.18 | 100 |
NLCT-AD18.5 | 18.5 | 0.73 | 14.3 | 0.56 | 40 | 1.57 | 100 |
NLCT-AD21.2 | 21.2 | 0.83 | 17 | 0.67 | 45 | 1.77 | 100 |
NLCT-AD25 | 25 | 0.98 | 20 | 0.79 | 45 | 1.77 | 100 |
NLCT-AD28.5 | 28.5 | 1.12 | 23 | 0.91 | 50 | 1.97 | 50 |
NLCT-AD34.5 | 34.5 | 1.36 | 29 | 1.14 | 60 | 2.36 | 50 |
NLCT-AD42.5 | 42.5 | 1.67 | 36 | 1.42 | 70 | 2.76 | 50 |
NLCT-AD54.5 | 54.5 | 2.15 | 48 | 1.89 | 90 | 3.54 | 25 |
NLCT-AD67.2 | 67.2 | 2.65 | 56 | 2.2 | 110 | 4.33 | 25 |
NLCT-AD80 | 80 | 3.15 | 69 | 2.72 | 140 | 5.51 | 25 |
NLCT-AD106 | 106 | 4.17 | 91 | 3.58 | 170 | 6.69 | 25 |
